SE Mode

RCA Input Impedance

47kΩ

Input Sensitivity

0.775V at 4Ω 120W

Voltage Gain

39dB at 1kHz

Frequency Response

20Hz-20kHz ±0.15dB

Output Power

2 x 120W at 1% THD+N, 20Hz – 20kHz

Dynamic Range

117dB

THD+N

THD+N = 0.002% at 1W

Output Impedance

＜25mΩ

BTL Mode

XLR Input Impedance

47kΩ

Input Sensitivity

0.775V at 4Ω 450W

Voltage Gain

58dB at 1kHz

Frequency Response

20Hz-20kHz ±0.3dB

Output Power

1 x 450W at 1% THD+N, 20Hz – 20kHz

Dynamic Range

121dB

THD+N

THD+N = 0.002% at 1W

Output Impedance

＜25mΩ

Power Voltage

230V position is fit for AC 170V-240V 50/60Hz

115V position is fit for AC 100V-132V 50/60Hz

Power Consumption

15～600W

Demention

160×205×47mm (L×W×H, Including the protruding part)

Weight

1.4kg
